    iTPS series
    NTEP certified Legal-For-Trade.
    Pallet Truck with Digital Scale allows you to weigh your load on the spot for maximum efficiency.
    Functions: net/gross weight display, weighing unit change, tare, accumulation.
    TARE function for manual deduction of a known container weight. (e.g. pallet, mesh crate etc.)
    One-push check of net/gross weight.
    80mm low fork height, selectable narrow (555mm) or wide (688mm) forks.
    180° pivot range.
    Castors: solid rubber on aluminum rims.
    Approvals: OIML; NTEP
    Conforms to ANSI B56.1/ EN1757-2

    Technical Data
    Display: 52 mm digit height LCD with white LED backlight.
    Operation temperature: -10 °C to 40 °C.
    Power: Internal 6V/10Ah rechargeable lead-acid battery pack.
    Dimension (LxWxH): 1630x555/688x1210 mm
    Net weight: 160kg
    Readability: 1kg

    Options:
    Optional thermal printer
    i-LIFT NO. Model No. Capacity kg(lb.) Min. Fork Height mm(in.) Max. Fork Height mm(in.) Fork Length mm(in.) Overall Forks Width mm(in.)
    1212301 iTPS20S 2273 (5000) 80 (3.1) 190 (7.5) 1160 (45.7) 555 (21.8)
    1212302 iTPS20L 2273 (5000) 80 (3.1) 190 (7.5) 1230 (48.4) 688 (27)
    1212303 iTPSP20S 2273 (5000) 80 (3.1) 190 (7.5) 1160 (45.7) 555 (21.8)
    1212304 iTPSP20L 2273 (5000) 80 (3.1) 190 (7.5) 1230 (48.4) 688 (27)
