      Home >> Miscellaneous >> Wire Rack >> TYX Series

    TYX Series
    ▲ Supporting the wire disc with using the matching fork when placing the wire in the wild;
    ▲ The modular structure makes it easy to disassemble packaging and transportation.
    i-LIFT NO. Model No. Capacity kg(lb.) Applicable Reel Diameter mm(in.) Applicable Reel Width mm(in.) Net Weight kg(lb.)
    2515003 TYX-1 1000(2200) Ф300-Ф1000(11.8-39.4) 300-750(11.8-29.5) 30.8(67.8)
    2515004 TYX-2 2000(4400) Ф1000-Ф1500(39.4-59) 300-800(11.8-31.5) 33.5(73.7)
    2515005 TYX-3 3000(6600) Ф1500-Ф2500(59-98.4) 300-1000(11.8-39.4) 180(396)
    2515001 TYX-4 4000(8800) Ф1500-Ф3500(59-137.8) 100-1200(3.9-47.2) 228(501.6)
    2515002 TYX-4A 8000(17600) Ф1500-Ф3500(59-137.8) 100-1200(3.9-47.2) 278(611.6)
    2515006 TYX-5 3000(6600) Ф100-Ф1200(3.9-47.2) 100-1500(3.9-59) 71.5(157.3)
