| Rated Capacity kg(lb.)： | 3000 (6600) |
| Standard Lifting Height mm(in.)： | 3000/5000 (118.1/196.9) |
| Effort to Rated Capacity (N)： | 360 |
| Diameter of Load Chain mm(in.)： | φ8×24 (φ0.3×0.9) |
| No.of Load Chain Falls： | 2 |
| Net Weight kg(lb.)： | 20.2/22.7 (44.4/50) |
| Min. Distance between Hooks mm(in.)： | 470 (18.5) |
| Test Load (KN)： | 37.5 |
| Extra Weight Per Meter of Extra Lift kg(lb.) ： | 3.7 (8.1) |
| Dimensions A mm(in.)： | 178 (6.8) |
| Dimensions B mm(in.)： | 139 (5.6) |
| Dimensions C mm(in.)： | 32 (1.2) |
| Dimensions D mm(in.)： | 178 (7) |
| Gross Weight kg(lb.)： | 20.8/23.3 (45.8/51.3) |
