| Capacity kg(lb.)： | 1500 (3300) |
| Min. Fork Height mm(in.)： | 75 (3) |
| Max. Fork Height mm(in.)： | 195 (7.7) |
| Load Center mm(in.)： | 600 (23.6) |
| Wheelbase mm(in.)： | 1280 (50.4) |
| Overall Forks Width mm(in.)： | 630 (24.8) |
| Fork dimentions mm(in.)： | 1200×160×50 (47.2×6.3×2) |
| Inner Width between Forks mm(in.)： | 310 (12.2) |
| Front Wheel mm(in.)： | φ75×95 (φ3×3.7) |
| Driving Wheel mm(in.)： | φ250×80 (φ10×3.1) |
| Balance Wheel mm(in.)： | φ75×35 (φ3×1.4) |
| Wheels Material/Number (Front/Driving/Balance Wheel)： | Polyurethane,4/1/2 |
| Front Wheel Distance mm(in.)： | 470 (18.5) |
| Balance Wheel Distance mm(in.)： | 485 (19.1) |
| Overall Dimensions mm(in.)： | 1665×720×1310 (65.6×28.3×51.6) |
| Length to Front Face of Forks mm(in.)： | 465 (18.3) |
| Ground Clearance,centre of wheelbase mm(in.)： | 30 (1.2) |
| Turning Radius mm(in.)： | 1465 (57.7) |
| Aisle width for pallets 800×1200 lengthways mm(in.)： | 1865 (73.4) |
| Aisle width for pallets 1000×1200 crossways mm(in.)： | 1630 (64.2) |
| Travel Speed(with/without load) (Km/h)： | 4.0/3.5 |
| Max. Gradeability(with/without load) (%)： | 5 |
| Service Brake： | Electromagetic |
| Drive Motor (W)： | 700 |
| Lift Motor (W)： | 800 |
| Battery (V/Ah)： | Capacity at 5 hours rate,24/70,95, weight 2×17.5/2×20 (2×38.5/2×44) |
| Battery Charger (A/V)： | 115V/230V,60Hz |
| Net Weight kg(lb.)： | 270 (594) |
| Type： | Electric,Pedestrian,without platform |
