| Capacity kg(lb.)： | 240 (528) |
| Max. Working Height mm(in.)： | 5000 (196.9) |
| Max. Platform Height mm(in.)： | 3000 (118.1) |
| Platform Size mm(in.)： | 1170×600 (46.1×23.6) |
| Min. Turning Radius mm(in.)： | 1200 (47.2) |
| Max. Machine Height mm(in.)： | 4120 (162.2) |
| Overall Size mm(in.)： | 1180×760×1830 (46.4×29.9×72) |
| Wheelbase mm(in.)： | 990 (39) |
| Ground Clearance mm(in.)： | 60 (2.3) |
| Max. Driving Speed(Platform Stowed/Raised) (Km/h)： | 4/0.8 |
| Raising/Lowering Time (sec.)： | 20/30 |
| Max. Gradeability (%)： | 10～15 |
| Max. Working Angle (°)： | 2° |
| Control： | PG |
| Drive Wheel mm(in.)： | φ230×80 (φ9×3.1) |
| Turning Wheel mm(in.)： | φ150 (φ6) |
| Driving Motor (V/Kw)： | 2×24/0.4 |
| Lifting Motor (V/Kw)： | 24/0.8 |
| Battery (V/Ah)： | 2×12/80 |
| Charger (V/A)： | 24/12 |
| Net Weight kg(lb.)： | 490 (1078) |
