| Capacity kg(lb.)： | 1000 (2200) |
| Min. Fork Height mm(in.)： | 88 (3.5) |
| Max. Fork Height mm(in.)： | 1600 (63) |
| Fork Length mm(in.)： | 1150 (45.3) |
| Overall Forks Width mm(in.)： | 540 (21.3) |
| Fork Dimension mm(in.)： | 160 (6.3) |
| Load Centre mm(in.)： | 550 (21.7) |
| Overall Length mm(in.)： | 1700 (70.1) |
| Overall Width mm(in.)： | 800 (31.5) |
| Overall Height mm(in.)： | Closed Mast Height,2078 (81.8) |
| Load Distance mm(in.)： | 295 (11.6) |
| Wheelbase mm(in.)： | 1280 (50.4) |
| Ground Clearance mm(in.)： | 24 (0.9) |
| Front Load Roller mm(in.)： | PU,φ80×70 (φ3×2.6) |
| Steering Wheel mm(in.)： | PU,φ180×50 (φ7×2) |
| Turning Radius mm(in.)： | 1580 (62.2) |
| Lift Motor (W/V)： | 1500/12 |
| Lifting Speed (with/without load) (mm/s)： | 84/145 |
| Lowering Speed (with/without load) (mm/s)： | 110/89 |
| Aisle Width for Pallets 1000*1200 Crossways mm(in.)： | 2390 (94.1) |
| Aisle Width for Pallets 800*1200 Lengthways mm(in.)： | 2380 (93.7) |
| Battery (V/Ah)： | 12/100 |
| Charger (A/V)： | 10/12 |
| Net Weight kg(lb.)： | with battery,240 (428) |
| Steering Handle： | O |
