| Capacity kg(lb.)： | 2000 (4400) |
| Min. Fork Height mm(in.)： | 85 (3.3) |
| Max. Fork Height mm(in.)： | 205 (8.1) |
| Load Center mm(in.)： | 600 (23.6) |
| Wheelbase mm(in.)： | 1400 (56.3) |
| Overall Forks Width mm(in.)： | 530/680 (20.9/26.8) |
| Fork dimentions mm(in.)： | 1150×160×56 (45.3×6.3×2.2) |
| Front Wheel mm(in.)： | φ80×70 (φ3×2.8) |
| Driving Wheel mm(in.)： | φ230×80 (φ9×3) |
| Balance Wheel mm(in.)： | φ125×75 (φ5×2.9) |
| Wheels Material/Number (Front/Driving/Balance Wheel)： | Polyurethane,4/1/2 |
| Overall Dimensions mm(in.)： | 1893/2289×730×1336 (74.5/90.1×28.7×52.6) |
| Turning Radius mm(in.)： | 1725 (67.9) |
| Travel Speed(with/without load) (Km/h)： | 7.0/7.2 (4.3/4.5 Mph) |
| Lift Speed(with/without load) (mm/s)： | 21.5/31 |
| Lowering Speed(with/without load) (mm/s)： | 26.7/29.5 |
| Max. Gradeability(with/without load) (%)： | 8 |
| Service Brake： | Electromagetic |
| Drive Motor (W)： | 1500,AC |
| Lift Motor (W)： | 800 |
| Battery (V/Ah)： | 24/210, 185kg (407lb.) |
| Net Weight kg(lb.)： | without battery,453/458 (996.6/1007.6) |
| Type： | Electric,Standing,witho platform |
