| Capacity kg(lb.)： | 1500 (3300) |
| Min. Fork Height mm(in.)： | ≤90 (≤3.5) |
| Max. Fork Height mm(in.)： | 4500 (177.2) |
| Fork Length mm(in.)： | 1150 (45.3) |
| Overall Forks Width mm(in.)： | 560/680 (22/26.8) |
| Fork Thickness mm(in.)： | 56 (2.2) |
| Individual Fork Width mm(in.)： | 160 (6.3) |
| Load Centre mm(in.)： | 600 (23.6) |
| Overall Dimensions mm(in.)： | 2065×900×2092 (81.3×35.4×82.4) |
| Extended Mast Height mm(in.)： | 4972 (195.7) |
| Wheelbase mm(in.)： | 1371 (54) |
| Ground Clearance mm(in.)： | ≥30 (≥1.2) |
| Front Load Roller mm(in.)： | φ78×70 (φ3×2.8) |
| Steering Wheel mm(in.)： | φ125×75 (φ5×3) |
| Driving Wheel mm(in.)： | φ230×80 (φ9×3.1) |
| Turning Radius mm(in.)： | 1640 (64.6) |
| Traveling Motor (W/V)： | 1500/17(AC) |
| Traveling Speed(Loaded/Unloaded) (Km/h)： | 5.2/6.5 |
| Lifting Motor (W/V)： | 3000/24(DC) |
| Lifting Speed(Loaded/Unloaded) (mm/s)： | 125/165 |
| Lowering Speed(Loaded/Unloaded) (mm/s)： | 94/120 |
| Battery (V/Ah)： | 24/240 |
| Net Weight kg(lb.)： | without battery,1180 (2596) |
| Full Free Lifting Height mm(in.)： | 1550 (61) |
| Type： | Electric,Standing,with platform and armrest |
| Min. Stacking Aisle mm(in.)： | ≥2550 (≥100.4) |
| Climb Gradient Loaded (%)： | 5 |
| Turning Motor (W/V)： | 150/24(DC) |
