| Power Type： | Diesel |
| Rated Capacity kg(lb.)： | 5000 (11000) |
| Load Center mm(in.)： | 600 (23.6) |
| Lifting Height mm(in.)： | 3000 (118.1) |
| Free Lift Height mm(in.)： | 160 (6.3) |
| Fork Size mm(in.)： | 1220×150×60 (48×5.9×2.4) |
| Mast Tilting Angle(F/R) (°)： | 6/12 |
| Front Overhang mm(in.)： | 635 (25) |
| Rear Overhang mm(in.)： | 600 (23.6) |
| Overall Length mm(in.)： | 4692 (184.7) |
| Overall Width mm(in.)： | 1995 (78.5) |
| Length to Face of Fork mm(in.)： | 3472 (136.7) |
| Mast Height mm(in.)： | Lowered,2519 (99.2) |
| Safeguard Height mm(in.)： | 2500 (98.4) |
| Min. Turning Radius mm(in.)： | 3300 (129.9) |
| Min. Right Angle Aisle Width(AST) mm(in.)： | 3090 (121.7) |
| Travel Speed (Km/h)： | 24 |
| Lifting Speed (mm/sec.)： | Loaded, 390 |
| Max. Gradeablity (%)： | 20 |
| Tyres(Front/Rear)： | 8.25-15-14PR/8.25-15-14PR |
| Tread(Front/Rear) mm(in.)： | 1470/1700 (57.9/66.9) |
| Wheelbase mm(in.)： | 2250 (88.6) |
| Ground Clearance mm(in.)： | 150 (5.9) |
| Self Weight kg(lb.)： | 8000 (17600) |
| Battery (V/Ah)： | 2×12/105 |
| Engine Model： | ISUZU 6BG1 |
| Engine-Rated Output/r.p.m (Kw/rpm)： | 82.3/2000 |
| Engine-Rated Torque/r.p.m (Nm/rpm)： | 416/1400～1600 |
| Engine-Displacement (cc)： | 6494 |
| Engine-Fuel Tank Capacity L(gallon)： | 140 (37) |
| Transmission Type： | Chinese,Hydraulic |
| Transmission Shift： | 6/12 |
| Operating Pressure-For Attachments (Mpa)： | 17 |
