| Power Type： | Diesel |
| Rated Capacity kg(lb.)： | 4500 (9900) |
| Load Center mm(in.)： | 500 (19.7) |
| Lifting Height mm(in.)： | 3000 (118.1) |
| Free Lift Height mm(in.)： | 150 (5.9) |
| Fork Size mm(in.)： | 1070×150×55 (42.1×5.9×2.2) |
| Mast Tilting Angle(F/R) (°)： | 6/12 |
| Front Overhang mm(in.)： | 562 (22.1) |
| Overall Width mm(in.)： | 1485 (58.5) |
| Length to Face of Fork mm(in.)： | 3091 (121.7) |
| Mast Height mm(in.)： | Lowered/Extended,2380/4250 (93.7/167.3) |
| Safeguard Height mm(in.)： | 2290 (90.2) |
| Min. Turning Radius mm(in.)： | 2790 (109.8) |
| Min. Right Angle Aisle Width(AST) mm(in.)： | 3415 (134.4) |
| Travel Speed (Km/h)： | (Forward I,Forward Ⅱ,Backward I)(Unloaded/Loaded) 15/14,22/20,15/14 |
| Lifting Speed (mm/sec.)： | Unloaded/Loaded, 480/450 |
| Max. Drawbar Pull (KN)： | 21 |
| Max. Gradeablity (%)： | Unloaded/Loaded, 18/17 |
| Tyres(Front/Rear)： | 300-15-14PR/7.00-12-12PR |
| Tread(Front/Rear) mm(in.)： | 1180/1190 (46.5/46.9) |
| Wheelbase mm(in.)： | 2000 (78.7) |
| Ground Clearance mm(in.)： | (Mast,Frame)(Unloaded/Loaded),175/145 (6.9/5.7),190/180 (7.5/7.1) |
| Wheel Width mm(in.)： | 1465 (57.7) |
| Self Weight kg(lb.)： | 6770 (14894) |
| Battery (V/Ah)： | 2×12/60 |
| Fork Spread(Outside Min./Max.) mm(in.)： | 300～1200 (11.8～47.2) |
| Engine Model： | WEICHAI 4105 |
| Engine-Rated Output/r.p.m (Kw/rpm)： | 68/2000 |
| Engine-Rated Torque/r.p.m (Nm/rpm)： | 340/1400～1600 |
| Engine-No. of Cylinder (Pcs)： | 6 |
| Engine-Bore×Stroke mm(in.)： | 105×125 (4.1×4.9) |
| Engine-Displacement (cc)： | 6494 |
| Engine-Fuel Tank Capacity L(gallon)： | 90 (23.8) |
| Transmission Type： | Chinese,Hydraulic |
| Transmission Shift： | 2/1 |
| Operating Pressure-For Attachments (Mpa)： | 17 |
