| Capacity kg(lb.)： | 160 (352) |
| Max. Working Height mm(in.)： | 13700 (539.4) |
| Max. Platform Height mm(in.)： | 12000 (472.4) |
| Platform Size mm(in.)： | 1330×600 (52.3×23.6) |
| Overall Dimensions mm(in.)： | 1590×1020×2180 (62×40×85.8) |
| Outspread Size mm(in.)： | 2760×2400 (108.7×94.5) |
| Lifting Motor (V/Kw)： | 1500 |
| Net Weight kg(lb.)： | 840 (1848) |
| Voltage： | AC,220V/50Hz |
| Type： | Self-Propelled |
|
