| Capacity kg(lb.)： | 136 (299.2) |
| Max. Working Height mm(in.)： | 6200 (244.1) |
| Max. Platform Height mm(in.)： | 4500 (177.2) |
| Platform Size mm(in.)： | 630×650 (24.8×25.6) |
| Overall Dimensions mm(in.)： | 1420×800×1970 (56×31.5×77.6) |
| Max. Driving Speed (Platform Stowed/Raised) (Km/h)： | 2.5/0.8 |
| Max. Climbing Capacity (%)： | 20 |
| Driving Motor (V/Kw)： | 24/0.8 |
| Lifting Motor (V/Kw)： | 24/0.8 |
| Battery (V/Ah)： | DC,24V |
| Net Weight kg(lb.)： | 690 (1518) |
| Number of Person Allowed： | 1 |
| Type： | Self-Propelled |
