| Capacity kg(lb.)： | 240 (528) |
| Max. Working Height mm(in.)： | 5000 (196.9) |
| Max. Platform Height mm(in.)： | 3000 (118.1) |
| Platform Size mm(in.)： | Stowed/Extended,1180×710/720 (46.4×7.9/28.3) |
| Min. Turning Radius mm(in.)： | Inside/Outside,0/1000 (0/39.3) |
| Overall Size mm(in.)： | 1180×760×1820 (46.4×29.9×71.6) |
| Wheelbase mm(in.)： | 990 (39) |
| Ground Clearance mm(in.)： | 60 (2.3) |
| Max. Driving Speed(Platform Stowed/Raised) (Km/h)： | Platform without Extended,4/0.8 |
| Raising/Lowering Time (sec.)： | 17/17 |
| Max. Gradeability (%)： | 25 |
| Max. Working Angle (°)： | 2° |
| Drive System： | Dual front wheel |
| Control： | Proportional |
| Drive Wheel mm(in.)： | φ230×80 (φ9×3.1) |
| Turning Wheel mm(in.)： | φ150 (φ6) |
| Driving Motor (V/Kw)： | DC,2×24/0.4 |
| Lifting Motor (V/Kw)： | DC,24/0.8 |
| Battery (V/Ah)： | 2×12/80 |
| Charger (V/A)： | 24/8 |
| Battery Weight kg(lb.)： | 34 (74.8) |
| Net Weight kg(lb.)： | 595 (1309) |
| Max. Platform Occupancy (Indoor/Outdoor)： | 2/1 |
