| Capacity kg(lb.)： | 200 (440) |
| Max. Platform Height mm(in.)： | 3300 (129.9) |
| Max. Working Height mm(in.)： | 5300 (208.7) |
| Max. Machine Height mm(in.)： | 4900 (192.9) |
| Ground Clearaance mm(in.)： | 30 (1.2) |
| Platform Size mm(in.)： | 600×640 (23.6×25.2) |
| Max. Driving Speed (Platform stowed/raised) (Km/h)： | - |
| Min. Turning Radius mm(in.)： | - |
| Max. Climbing Capacity： | - |
| Driving Wheel Size mm(in.)： | - |
| Caster mm(in.)： | - |
| Driving Motor (V/Kw)： | - |
| Controller： | - |
| Lifting Moter (V/Kw)： | 12/1.5 |
| Battery (V/Ah)： | 12/120 |
| Charger (V/A)： | 12/15 |
| Overall Size mm(in.)： | 1300×840×2040 (51.2×33.1×80.3) |
| Net Weight kg(lb.)： | 320 (704) |
